Weighing just 4.3 kg with a 42.9 cm³ engine that provides 2.3 kW power the CS-4310SX has the best power to weight ratio in its class.
Features for the professional.
The CS-4310SX is packed with features to increase your productivity:
Heavy-duty aluminum handle with rubber grip for secure grip and 3-point anti vibration spring.
Features for easy maintenance:
Momentary switch for quick and easy engine restart.
Rotating plastic chain catcher.
Side access chain tensioner for easy chain adjustment.
Flip lever caps for easy refilling.
Drop prevention nuts as standard.
Translucent fuel tank shows fuel level.
Centrifugal separation system.
Centrifugal separation dust free system massively reduces the need for maintenance by removing dust and debris in stages before air even reached the automotive style air filter.
Product Details.
| Carburettor | Diaphragm |
|---|---|
| Engine displacement (cm³) | 42.9 |
| Output (kw) | 2.3 |
| Dry Weight (kg) | 4.3 |
| Fuel tank capacity (l) | 0.40 |
| Chain Oil Tank Capacity (ml) | 270 |
| Fuel Consumption At Maximum Engine Power (L/h) | 1.24 |
| Saw Chain Pitch (inch) | 0.325 |
| Guide Bar Gauge (inch) | 0.050 |
| Applicable Bar Length (cm/inch) 1 | 40/16 |
| Sound pressure level (dB(A)) | 103.1 |
| Sound power level (dB(A)) | 113.0 |
| CO² (g/kW・h) 2 | 846 |
| Vibration Front handle/Rear handle (m/s²) |
3.3 / 3.1 |
1Not all lengths available in every country. Available bar lengths may incur differing RRPs. Please check with your local dealer.2This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.
