Featuring a 34.0cm³ professional grade engine, giving exceptional power to weight ratio.
Compact, ergonomic design
ECHO chain saws are all designed to the same professional standard, with no exceptions. Hard working, high quality with renowned Japanese build standards.
Ergonomic
Superbly balanced and lightweight making it ideal for a diverse range of jobs.
Product Details.
| Engine displacement (cm³) | 30.5 |
|---|---|
| Output (kw) | 1.1 |
| Output (ps) | 1.5 |
| Dry Weight (kg) | 4.0 |
| Fuel tank capacity (l) | 0.25 |
| Chain Oil Tank Capacity (ml) | 260 |
| Fuel Consumption At Maximum Engine Power (L/h) | 0.68 |
| Priming Pump | Yes |
| Ignition System | CDI |
| Start Assist System | ES-start |
| Chain Brake | Inertia |
| Choke w/ Automatic Fast Idle Release | Yes |
| Chain Tensioner | Side |
| Saw Chain Pitch (inch) | 3/8 |
| Guide Bar Gauge (inch) | 0.050 (0.043) |
| Applicable Bar Length (cm/inch) 1 | 30,/12 |
| Sound pressure level (dB(A)) | 97.9 |
| Sound power level (dB(A)) | 107.7 |
| CO² (g/kW・h) 2 | 1128 |
| Vibration Front handle/Rear handle (m/s²) | 4.1 / 6.8 |
1Not all lengths available in every country. Available bar lengths may incur differing RRPs. Please check with your local dealer.2This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.
